ממיר מ-VGA + AUDIO TO HDMI
ממיר מ-VGA + AUDIO TO HDMI
18131 :מק"ט
ממיר אקטיבי VGA + AUDIO TO HDMI, כניסת אודיו 3.5ST בצד ה-INPUT, מגיע עם ספק כח.
הורדת מפרט טכני• lnput: VGA x 1, 3.5mm audio x 1
• Output: HDMI x 1
• lnput VGA resolution supported: 640 x 480@60Hz, 800x600@60Hz, 1024x768@60Hz, 1280x720@60Hz,
1280x768@60Hz, 1360x768@60Hz, 1440x900@60Hz, 1600x1200@60Hz, 1680x1050@60Hz,
1920x1080@ 60Hz.
1280x768@60Hz, 1360x768@60Hz, 1440x900@60Hz, 1600x1200@60Hz, 1680x1050@60Hz,
1920x1080@ 60Hz.
• This is a pass through solution, the output resolution is the same as the resolution input.
Item |
VGA to HDMI converter 1080P@60HZ |
Model |
18131 |
Power supply |
12VDC/1A (Adaptor) 12VDC (emergency power from monitor |
Input VGA resolution supported |
Duplex communication |
Audio input signal |
0.1Lux (up to 300mm from camera / with normal LED operation) |
DOC signal |
White LED equipped (night vision) |
TMDS signal |
CMOS IMAGE SENSOR (0.52 megapixels) |
Output HDMI resolution supported |
93° horizontal, 50° vertical, 110° diagonal |
Consumption |
13° (pan and tilt) |
Dimension |
13.56MHz |
