24+2+2 port 100m POE switch

08016 :מק"ט

הורדת מפרט טכני
• 24*100/1000Mbps PoE ports; 2*100/1000Mbps Uplink Ports; 2*100/1000mbps SFP
• 100m Distance
• Support IEEE802.3AF/AT
• Whole Power: 400W(52V 7.7A)
• All port supported by MDI/MDIX auto flip and self-negotiation
• Supply 20*10/100/1000Mpbs adaptive high speed forwarding data packet non-lost port.
• Support IEEE802.3x flow control for Full-duplex mode and backpressure for Half-duplex mode.
• Each port max. Power supply reached 30W.
• Application: Wireless Access Point, IP Camera, IP Phone, Computer Networks
• AI Watchdog
08016-spec

 Product

 24+2+2 port 250m POE switch

 Model No.

 08016

 PoE Port

 1 to 24 port support 100mbps IEEE802.3af/at

 UP link port

 25th-28th port support 1000Mbps

 PoE output

 15.4W/30W IEEE802.3af/at

 PoE whole power

 <=400W(52V 7.7A)

 PoE type

 End-span

 Power distance

 <=100m

 Network Standard

 IEEE 802.3, IEEE802.3u,802.3x,802.3af/at

 Network Medium

 100/1000BASE-TX: 5 class and above non shielded twisted pair

 Data Distance

 <=100m

 Switch capability

 56Gbps

 Forwarding Mode

 Store and forward

 Forwarding Rate

 • 10BASE-T:14880pps/port

 • 100BASE-tx:14800pps/port

 • 1001000BASE-T: 1488000pps/port

 MAC Address

 16K MAC address table

 Port function

 Power priority mechanism, fast and forward, MAC automatic learning and aging

 IEEE802.3X Full-duplex and mode and backpressure for Half-duplex mode

 Indicator

 LINK/ACT. 100Mbps;POE Status indicator; POWER indicator

 Working Environment

 Working Temperature: -10°-- 55°C

 Input power

 AC100-240V 50/60HZ

 Weight

 4.2kg

 Size

 440mm*210mm*44mm(L*W*H)
