08015 :מק"ט

הב סוויטצ מנוהל 24 פורטים 100/1000 PoE משולב 4 פורטים Up-Link 100/1000 ו-4 פורטים SFP.
תוצרת COPA
כניסת Console Port
הספק כולל 400W וואט
תומך + PoE
הספק מקסימלי לפורט בודד 30W
מיועד למצלמות IP, טלפוני IP אקסס פוינטים וכל צרכן PoE אחר
חיבור מתח 220VAC
כולל אוזניים לארון תקשורת "19

הורדת מפרט טכני הורדת קבצי התקנה
- Supply 24*10/100/1000Mbps RJ45 Port (Support PoE+).
- Supply 4*10/100/1000Mbps RJ45 Uplink Port.
- Supply 4*10/100/1000Mbps SFP Port.
- Supply 1*Console RJ45 Port.
- Support 802.1Q VLAN, Port VLAN, QoS, Rate Limit, Storm-control.
- Support port aggregation, mirroring, monitoring, cable test, self-loop.
- Support Web manage, VLAN, standard model.
08015-spec1 Hardware Specification:

 Product

 Active 24+4+4 Full Gigabit Managed PoE Switch

 Model No.

 08015

 Port

 24*10/100/1000Mbps adaptive port, Support PoE

 4*10/100/1000Mbps RJ45 Uplink Port

 4*10/100/1000Mbps SFP Port

 1*Console RJ45 Port

 LED Indicator

 Power, SYS, Link /Act: 10/100/1000Mbps, POE

 Size

 440mm×284mm×44mm(L×W×H)

 Environment

 Operating temperature: 10?-50?
 Storage temperature: -40?-70?
 Operating humidity 10%-90% non-condensing

 Storage humidity 5%-90% non-condensing

 The Whole Power

 400W

 PoE Power

 <400W

 Standard

 IEEE802.3, 802.3u, 802.3x, 802.3af, 802.3at CSMA/CD,TCP/IP

 Basic Function

 Compatible with PD devices of IEEE802.3 af/802.3 at standard Power priority     mechanism
 Fast and forward
 MAC automatic learning and aging
 IEEE802.3X Full-duplex and mode and backpressure for Half-duplex mode

 Switching  Capacity

 52Gbps

 MAC address table

 8k

 Forwarding Rate

 10BASE-T: 14880pps/port

 100BASE-TX: 148800pps/port

 Forwarding Mode

 Store and forward

Software Specification:
08015-spec11111 Untitled-2 08015-spec2 08015-spec3

 Port Setting

 Abled/disabled
 Speed,duplex, MTU setting

 Flow-control
 Portchecking

 Mirroring

 By mirroring port transmission, receiving and sending and

 receiving data

 Port Rate Limit

 Support rate limit, decided by chipset

 Port Isolation

 Support isolation setting

 Storm-control

 Support unknown multicast, unknown unicast, broadcast

 storm-control

 Link Aggregation

 Support static manually aggregation

 Support LACP dynamic aggregation

 VLAN

 Access/Trunk/Hybrid

 Support VLAN Dividing based on Port, Portocol, MAC, with QINQ

 Support GVRP dynamic VLAN registration

Voice VLAN (Support Needed)

 MAC

 Support static adding, deleting

 Limit on numbers of MAC Address Learning

 Support dynamic aging time setting

 SpanningTree

 Support 802.1d (STP); Support 802.1w(RSTP)

 Support 802.1s (MSTP)

 Multicast

 Support static adding, deleting; Support IGMP-Snooping;

 Support MLD-Snooping; Support v1/2/3 dyna micmul ticast checking

 DDM

 Support SFP/SFP+DDM

 ACL

 Based on source MAC, destination MAC,

 source IP, destination IP, L4 Port

 QOS

 Based on 802.1p (COS) sort; Based on DSCP sort;

 Based on source IP, destination IP; Support SP, WRR scheduling policy;

 Support rate limiting CAR

 LLDP

 Support LLDP link detect protocol

 User setting

 Adding/deleting

 Log

 User login, operation, status, event recording log

 Attack prevention

 DOS defense
 Support the protection of CPU, Limit rates of checking the CPU and memory  utilization ARP binding (IP, MAC, PORT binding)

 Certification

 Support port certificating of 802.1x; Support AAA certificating

 Network diagnosis

 Support ping, telnet, trace

 Management of  System

 Reset, save configuration / recovery, Upgrade,Time setting

Management Function:

 CLI

 Support CLI administration

 TELNET

 Support telnet remote administration

 SSH

 Support SSHv1/2 remote administration

 SNMP

 Supportv1/2/3
 Supporttrap: ColdStart, WarmStart, LinkDown, LinkUp

 Web

 Support L2 Setting; Support L2/3 Checking
 (IP:192.168.2.1, User/password: admin/admin)

 RMON

 Support RMON v1

 POE

 PoE Setting, PoE Timer Setting
