סוויצ 24+2 פורטים PoE
סוויצ 24+2 פורטים PoE
08013 :מק"ט
סוויצ 24 פורטים POE 10/100 משולב 2 פורטים UPLINK GIGA , הספק כולל 400W, הספק מקסימלי לפורט בודד 30W ,מרחק התקנה עד 250 מ´, מיועד למצלמות IP, טלפוני IP אקסס פוינטים וכו´, חיבור מתח 220VAC.
הורדת מפרט טכני• 250m Diatance
• Power Built-in
• VLAN Support
• Support IEEE802.3AF/AT
• Whole Power: 400W (52V 7.7A)
• Max. Power for Each port: 30W
• All port supported by MDI/MDIX auto flip and self-negotiation
• Support IEEE802.3x flow control for Full-duplex mode and backpressure for Half-duplex mode.
• Application: Wireless Access Point, IP Camera, IP Phone, Computer Networks
|
Product |
24+2 10/100Mbps 400W PoE Switch IEEE802.3af/at |
|
Model No. |
08013 |
|
PoE Port |
1 to 24 port support IEEE802.3af/at |
|
UP link port |
25th-26th port support 1000Mbps |
|
PoE output |
15.4W/30W IEEE802.3af/at |
|
PoE whole power |
<=400W |
|
PoE type |
End-span |
|
Power distance |
<=250m |
|
Network Standard |
IEEE 802.3? IEEE802.3u?802.3x?802.3af/at |
|
Network Medium |
100/1000BASE-TX: 5 class and above non shielded twisted pair |
|
Data Distance |
<=250m |
|
Switch capability |
12Gbps |
|
Forwarding Mode |
Store and forward |
|
Forwarding Rate |
• 100Mbps:14880pps • 1000Mbps:14800pps • 1000BASE-T: 1488095pps/port |
|
MAC Address |
2K MAC address table |
|
Port function |
Power priority mechanism, fast and forward, MAC automatic learning and aging IEEE802.3X Full- duplex and mode and backpressure for Half-duplex mode |
|
Indicator |
LINK/ACT. 100Mbps;POE Status indicator; POWER indicator EXTENDER indicator |
|
Working Environment |
Working Temperature: -10°-- 55°C |
|
Input power |
AC100-240V 50/60HZ |
|
Weight |
2.5kg |
|
Size |
270mm*180mm*44mm (L*W*H) |
