מרחיק HDMI 4K 70M

18124K :מק"ט

מרחיק HDMI BaseT סט משדר מקלט ע"ג כבל CAT6 , מתאים למרחק 70 מ´ תומך ב-FULL HD1080p@60HZ/3D,4Kx2K ותמיכה ב- HDCP/CEC/LPCM//DTS-HD.

הורדת מפרט טכני

• Incorporate HDbaseT extend technology
• Transmit uncompressed HDMI signal over CAT5e/6/6a/7 cable
• Support distance up to 230feet (70 meters) with CAT6a/7
• Support bidirectional IR pass-back function
• Support HDCP ,CEC, 24 deep color
• Support uncompressed LPCM audio and compressed DTS-HD, Dolby True HD

18124K

Model

HDMI EXTENDER

Item

4Kx2K, compatible with HDCP, support CEC and 24bits deep color

HDMI signal

480i/480P/576i/576P/720P/1080i/1080P/3D/4Kx2K

Resolution Supported

LPCM , DTS-HD, Dolby True HD

Audio

CAT5E, CAT6, CAT6A, CAT7

Network cable

UP to 1080p@60Hz 36bpp	60m
1080p@60Hz 48bpp, 1080p@60Hz 3D, 4Kx2K@30Hz, 4Kx2K@ 60Hz(4:2:0)	35m

CAT5E

UP to 1080p@60Hz 36bpp	70m
1080p@60Hz 48bpp, 1080p@60Hz 3D, 4Kx2K@30Hz, 4Kx2K@ 60Hz(4:2:0)	40m

CAT6

Transmission length

Support 20~60kHz wide frequency devices and Bi-directional IR transmission

Infrared back

DC12V/1A *2pcs

Power supply

TX<3.5W RX<6W

Power consumption

98.5(L)x66.5(W)x23(H)mm *2pcs

Product dimension

Metal

Enclosure material

TX:79g RX:107g

Weight

Black

Color
