מרחיק HDMI ברזולוציה 4K עד 70 מטר
מרחיק HDMI ברזולוציה 4K עד 70 מטר
18152 :מק"ט
מרחיק HDMI על גבי כבל רשת ברזולוציה 4Kx2K למרחק עד 70 מטר.
תומך בפרוטוקול RS-232
תומך PoE (הזנת מתח בצד של המשדר בלבד)
תומך העברת IR כפולה (ל2 צדדים)
המארז כולל:
משדר + מקלט
1 ספק 5V
4 עיניות IR
• Apply HDBaseT extend technology
• Support bi-directional IR pass back
• Support bi-directional RS232 control
• Apply HDBaseT transmission technology
• Support HDMI2.0 HDCP2.2 ,CEC, 24 deep color
• Support LPCM DTS-HD and Dolby True HD audio
• Supported resolution is up to 4Kx2K@60Hz ultra HD
• Transmit 4Kx2K@60Hz signal over cat6 up to 70 meters
• Can be powered by network cable. It only needs to connect
the 12V power on the receiver unit, both transmitter and receiver start work
• Support bi-directional IR pass back
• Support bi-directional RS232 control
• Apply HDBaseT transmission technology
• Support HDMI2.0 HDCP2.2 ,CEC, 24 deep color
• Support LPCM DTS-HD and Dolby True HD audio
• Supported resolution is up to 4Kx2K@60Hz ultra HD
• Transmit 4Kx2K@60Hz signal over cat6 up to 70 meters
• Can be powered by network cable. It only needs to connect
the 12V power on the receiver unit, both transmitter and receiver start work
| HDMI EXTENDER | Item |
| 18152 | Model |
| Support HDMI2.0 HDCP2.2, support CEC and 24bits deep color | Resolution Supported |
| 480i/480P/576i/576P/720P/1080i/1080P/3D/4Kx2K | Audio |
| LPCM?DTS Digital, Dolby Digital | Network cable |
| CAT6/CAT6A/CAT7 | Transmission length |
| 70m | IR control |
| Support 20~60kHz wide frequency devices and Bi-directional IR transmission | Working temperature |
| 0~55 | Storage temperature |
| -10~70 | Humidity |
| 0~90%(no condensation) | Power supply |
| DC12V/2A x1pcs | Power consumption |
| TX: <6W; RX: <8W | Product dimension |
| 109.49(L)x87.0(W)x23.4(H)mm | Material |
| TX:240g RX:250g | Weight |
| Black | Color |
