מוניטור טכנאים דגם IPC-9800CADH PLUS - כולל צלצלן

   LCD

  Item series

  IPC-9800 Plus series

  Display

  New 7 inch IPS touch screen, 1920*1200 resolution

 Video  Mode

  CVBS

  1 channel BNC input & 1 channel BNC looped output, NTSC/PAL (Auto adapt)

  Analog video level meter, peak video signal level, SYNC signal level, Color bar       chroma level measurement *

 PTZ control, RS485 control, Baud 600-115200bps,compatible with more than 30     protocols such as PELCO-D/P, Samsung, Panasonic etc

 CVBS loop test

  the tester send and receive color bar generator signal, check
  BNC cable

 IP camera test

 4k/H.265/H.264

 IP Discovery/Quick ONVIF/IPC test /RTSP play /Client APK

 Rapid Video

 Auto view the video, create testing report

 Hik test tool

 pressing just one key to activate hikvision camera , Image test,
 can modify the user name, password and IP parameters

 Dahua test tool

 Dahua camera test, modify the user name, password and IP   parameters

 IP& CVBS test

 IP& CVBS test at the same time, converter test from analog to digital with dual test   window

 Coaxial HD test*

 8MP TVI camera test, 3840 x 2160P 15FPS, UTC control/call OSD menu*

 8MP CVI camera test, 3840 x 2160P 12.5F/15F,UTC control/call OSD menu*

 8MP AHD camera test, 2560x1944P 15FPS, UTC control/call OSD menu*

 8MP EX-SDI, HD-SDI, 3G-SDI, UTC control & call OSD menu*

 HDMI input *

 1 channel HDMI input, support 1080P

 Zoom Image

 4x zoom, to enlarge image, Screen snapshot, record ,save ,view and record
 and play back

Analog

Video out

 color bar

 generator

 Output one channel PAL/NTSC color bar video signal for testing monitor or video     cable

power

output

PoE power output

 48V PoE power output, max power 25.5W

 12V/2A power

 Output DC12V/3A power out ,supply temporarily power for the camera

 5V/2A power     output

 USB 5V 2A power output, as a power bank

 Cable test

 TDR cable   test *

 BNC cable, network cable, telephone cable, RVV cable and elevator cable,     cat  5/6 cable´s length and short circuit. measurement range 1.2KM

 Cable tracer

 search BNC cable, network cable and telephone cable from the mess cables

 UTP cable   test

 Test UTP cable connection status and display on the screen. Read the number on  the screen

 RJ45 cable   TDR test

 test cable pair status, length, attenuation, reflectivity, impedance, skew etc,   measurement range 180M.

 TesterPlay

 Network test

 Trace route, Link monitor, DHCP server, port flashing, Ping test

 Wi-Fi

 Built in WIFI,speeds150M,display wireless camera image

 Audio test

 1 channel audio signal input, test whether sound normal, 1 channel audio signal, to connect   headphone

 Data monitor

 Captures and analyzes the command data from controlling device, also can send hexadecimal

 PoE test

 Measurement POE switch or PSE power supply voltage and cable connection status

 Drop-down menu

 You can select PoE power switch ,IP setting, WLAN switch , HDMI IN functions etc in any   interface

 External power  supply

 DC 12V 2A

 Batter

 Built-in 7.6V Lithium polymer battery,7500mAh

 Rechargeable

 After charging 3.5 hours, normal working time 16 hours

 Operation setting

 OSD menu, select your desired language: English, Chinese, Korean, Russian, Italian, French,   Polish, Spanish, Japanese etc

 Auto off

 1-30 (mins)

 Working   Temperature

 -10C---+50C

 Working Humidity

 30%-90%

 Dimension/Weight

 240mm x 154mm x 46mm / 620g

 Item

 Wire Tracker

 Emit signal

 Digital signal(rejects noise and false signals )

 Cable type

 RJ45 Twisted pair, RJ11 telephone line, BNC cable etc.

 UTP cable test

 The digital "1-8” for cable sequence shielded cable and shielding layer continuity indicator,   check cable type indicator: straight/cross/other, 100M/1000M Network cable test, and near-   end, mid-end, far-end continuity testing

 Continuity test of   RJ45 cable connectors

 Check wire continuity of both RJ45 cable connector

 PD (powered) test

 PoE switch power supplying status test and check the pins used for power supply.

 LED lamp

 Short press ON /OFF LED Light

 Silent mode

 Long press key "Mute” to switch silent mode, find cable through indicator

 Audio output

 Support external audio output

 External power supply

 Two AA battery

 Working Temperature

 -10C---+50C

 Working Humidity

 30%-90%

 Emitter Dimension

 152mm x 62mm x 27mm /0.12KG

 Receiver Dimension

 218mm x 48mm x 32mm /0.1KG
